224-310KW广西顶博发电机组制造:康明斯发电用发动机可靠性高：高强度合金铸造缸体、可锻铸铁(FCD) 活塞，刚性更好，降低振动和噪声，提高了发动机适应更高的爆发压力。

High reliability: intensified alloy casting cylinder and Ferrous Cast Ductile (FCD) piston provide engine a better rigidity performance and lower vibration & noise, and also make the engine adapt to higher explosion pressure.

康明斯火力发电用打火机汽油经济增长性好: 发达的汽油调控设备，才有的STC、ESTC 分级制度调控设备，特异设计的的活塞杆顶上丙烷冷却系统，进行高压压喷射汽油，足够吸雾，丙烷自燃足够。

Good fuel economy: Advanced fuel control system, unique STC, ESTC step control system, specilly-designed piston topchamber and high pressure fuel injection lead to an excellent fuel consumption rate and emission performance of engine.

康明斯发电机组用发起机瞬态特点比较好: 无暇的发起机大体设计构思，互相配合康明斯特有的EFC体系，管理定位精度不高，没有响应时快。

Excellent transient performance: perfect overall engine design with unique Cummins EFC system, high precision on control and quick response time.

康明斯带发电用启因素升输出高: 产品 设计构思紧身.外表装置合理安排，作业能保持稳定。High lift power: Integrated and compact design, reasonable layout and smooth operation.

电喷机种 QSNT. QSK19. QSK38. QSK50无法全球非路途再者的阶段及北美地区Tier2. Tier 3减排法律规定追求。

Electric fuel injection engines (QSNT,QSK19,QSK38,QSK50) meet the Tier3 emission regulations for China non-road vehicles and Tier2 & Tier3 emission regulations of North America.

零备用件可知性好， 打着机运营及保护维护便民，的效率高。Good availbility of spare parts, smooth engine operation, convenient engine maintenance and low cost.

发动机规格Engine Specifications

电功率範圍 Power Range   224-310KW结构类型 Type   直列/六缸/四冲程/四气门  In-ine/6-Cylinder/4-Stroke/4-Valve缸径x冲程 BoreX Stroke  125X 147mm排量 Displacement   11L形壮面积 Dimension  长X宽X高(LXWX H) 1360 x 833X 1068 mm净质 Dry Weight   940kg

224-310KW康明斯生产发电用打着机的亮点：容积小， 压缩成变高， 排水槽气采暖器，非常易开机，位移车载一体机电源适配器的都喜欢选用。Compact size, high compression ratio, gile heated by air, easy for start-up, the first option of mobile vehicle power supply.

推荐机型Engine Models Recommended

启驱力产品型号	经常用到耗油率(kW)Prime Power	预备额定功率kW)Standby Power
MTA11-G2	224	246
MTAA11-G3	282	310
